Replaced by SG745

GOBLIN 700 DRAKE EDITION ( with main and tail blades )

SKU: SG728 bar code: 8935254812944
Availability: Out of stock
Purchase and earn 798 points
GOBLIN 700 DRAKE EDITION ( with main and tail blades )
  • DRAKE new matte graphic scheme

Risorsa 1
Blade Size 690
Weight (no battery/fuel) 3750g
Power supply 12S 4500/5500 mAh

The Goblin Drake edition come from Goblin Sport 700
Using a Drake matt graphic scheme from SABAVIO jets, the Goblin 700 Drake get an awesome look.

Main and tail blades are included
Fiberglass canopy weighing in at 230gm.
Carbon tail boom
Strong, proven HPS black matte head, perfect for all flight abilities and conditions.
Stable wide landing gear, for safer landings and stable take offs. ( black and white colors are included)
G10 mainframe delivers performance on a budget. Compatible with the standard carbon frame to allow simple upgrading.

Kit includes:

• Motor pulley 21T

• 2 sets battery tray

• SAB blades and tail blades ( 690 TBS + 115 TBS )


Kit upgrades
Total price
GOBLIN 700 DRAKE EDITION ( with main and tail blades ) €798.00
Total €798.00
Out of stock
Discontinued Replaced by SG745

Helicopter Main Data

Configuration 700 Size
Available P/N SG712-SG714-SG715-SG715-SG718-SG708
Main rotor diameter 1548mm
Main blade length 690mm
Tail rotor diameter 305mm
Tail blade length 115mm
Main shaft diameter 12mm
Tail shaft diameter 6mm
Weight 3750g (ex. Battery)

Helicopters Secondary Data

Cyclic Servos Standard size 40mm
Tail Servo Standard size 40mm
Typical speed controller 160A
Maximum motor size 57 mm diameter x 63 mm height
Motor KV 520KV
Battery compartment 60x58x350mm
Battery capacity 12S 4500/5500 mAh
Available ratios From 8.6 to 11.9

Spare Parts

Uniball M3x4 D5 H18
H0063-S Uniball M3x4 D5 H18
Thread Rod M2,5X18
HC140-S Thread Rod M2,5X18
Nylon Nut M2.5
HC200-S Nylon Nut M2.5
Nylon Nut M3
HC206-S Nylon Nut M3
JR servo arm
HA051-S JR servo arm
Nylon Screw M8x20
HC165-S Nylon Screw M8x20
FBL support Low
H0727-S FBL support Low
Strap 20x250mm
HA041-S Strap 20x250mm
Zip Tie 2.5 x 200mm
HA058-S Zip Tie 2.5 x 200mm
