SG583

Goblin RAW 580

SKU: SG583
Availability: Low stock
Purchase and earn 738 points
€738.00
Goblin RAW 580
Risorsa 1
Blade Size 580
icona-peso
Weight (no battery/fuel) 2710gr
battery-icon_1
Power supply 12s 2600-3300, 6s 5000-5500

The new RAW 580 use the same module from Kraken 580.

-Incredible strong Power train enclosed in aluminum case,

-Ultra light 7075 aluminum alloy highly adjustable rotor head with super simple Tail group,

-Aluminum Boom 30 mm

-Easy maintenance

-Main blades up to 600mm.

TECHNICAL SPECITICATIONS

-AIRFRAME weight: 1740gr ( with S580 blades, no battery, no electronics )

-Main blade length: 550mm to 600mm

-Tail blade length: 95 to 105 mm

-Main rotor diameter: 1290 mm (with 580 mm blades included)

-Tail rotor diameter: 260 mm (with 95 mm tail blades included)

-Cyclic Servos: mini cyclic servo (torque over 8 Kg-cm). Kit includes servo mounts for mini-servos. Full size servo mounts available separately.

-Tail Servo: standard size 40mm.

-Main Rotor ratio : 11.5 to 8.6 :1 ( 22T included: 9.4:1)

-Tail Rotor ratio : 5.3-4.9:1 ( 23T included: 4.9:1 )

-Typical motor : 4025 series, 6S 1000-1200 Kv, 12S 500-600 Kv. Minimum motor shaft length is 26mm (We recommend using a 6mm diameter motor shaft)

-Typical speed controller: 6S 120-140 A, 12S 100-130A

-Battery size: 6S 5000/5800 mAh, 12S 2600/3200 mAh.

Kit upgrades
Total price
Goblin RAW 580 €738.00
Total €738.00

Helicopter Main Data

7
Configuration 580
Available P/N SG583
Main rotor diameter 1290mm with 580mm Main Blades
Main blade length 580mm to 600mm
Tail rotor diameter 260mm with 95mm Tail Blades
Tail blade length 95mm to 105mm
Main shaft diameter 10mm
Tail shaft diameter 5mm
Weight 1740gr ( with blades, no battery, no electronics )

Helicopters Secondary Data

Cyclic Servos Mini Size 36mm
Tail Servo Standard size 40mm
Typical speed controller 6S 120A, 12S 130A
Maximum motor size 52 mm diameter x 58 mm height
Motor KV 6S 1000-1400KV, 12s 500-700KV
Battery compartment 6S 50x60x200 mm, 12S 50x45x280 mm
Battery capacity 6S 5000/5500 mAh, 12S 2600/3300 mAh
Available ratios From 8.5 to 12.9

Spare Parts

Thread Rod M2,5X18
HC140-S Thread Rod M2,5X18
€5.50
Nylon Nut M2.5
HC200-S Nylon Nut M2.5
€5.50
Nylon Nut M3
HC206-S Nylon Nut M3
€4.50
Shims 8x 14 x 0,2mm
HC228-S Shims 8x 14 x 0,2mm
€5.50
JR servo arm
HA051-S JR servo arm
€19.00
Strap 20x250mm
HA041-S Strap 20x250mm
€7.00
Canopy Base
H1101-S Canopy Base
€24.00
Reference Pin
H1048-S Reference Pin
€5.00
Battery Tray
H1102-S Battery Tray
€21.00
Wire Cover
H1107-S Wire Cover
€9.00
Grease LDS
HA075-S Grease LDS
€11.00
Grease NBU
HA076-S Grease NBU
€11.00
Kraken Serial Plate
H1108-S Kraken Serial Plate
€6.00
Antenna Support
H1134-S Antenna Support
€7.00
STEEL MAIN SHAFT
H1299-S STEEL MAIN SHAFT
€18.00
WASHER SET
HC594-S WASHER SET
€16.00
Aluminum Block Nut M2
H1386-S Aluminum Block Nut M2
€18.00
Belt Tensioner
H1278-S Belt Tensioner
€18.00
CF Tail Fin
H1196-S CF Tail Fin
€19.00
Tensioner Idle
H1066-S Tensioner Idle
€15.00
Plastic Frame Spacer
H1340-S Plastic Frame Spacer
€14.00
Tail Orings
HC598-S Tail Orings
€7.00
Tail Blades S95
S95 Tail Blades S95
€27.00
Main Blades S580
S580 Main Blades S580
€84.00
FBL Rubber Pin
HC573-S FBL Rubber Pin
€8.00
Canopy Front Block
H1439-S Canopy Front Block
€10.00
Aluminum Top Case Aluminum Top Case
H1503-S Aluminum Top Case
€55.00
Aluminum Tail Pulley 23T
H1312-23-S Aluminum Tail Pulley 23T
€22.00
Canopy Base Support
H1440-S Canopy Base Support
€8.00
RAW 580 Canopy RAW 580 Canopy
H1438-S RAW 580 Canopy
€99.00
FBL/RX SUPPORT
H1625-S FBL/RX SUPPORT
€23.00
580 RAW MANUAL RELEASE 1.0

580 RAW MANUAL RELEASE 1.0
