SG580
SAB GOBLIN KRAKEN 580
The new Kraken 580 use the same concepts from the Kraken 700.
NEW BATCH AVAILABLE END OF JULY
The new Kraken 580 use the same concepts from the Kraken 700.
-Incredible strong Power train enclosed in aluminum case,
-Ultra light 7075 aluminum alloy highly adjustable rotor head with super simple Tail group,
-Body and boom design with integrated frames, to create a amazing fuselage style
-Boom detachment system for improved crash durability.
-Main blades up to 600mm.
TECHNICAL SPECITICATIONS
-AIRFRAME weight: 1760gr ( with blades, no battery, no electronics )
-Main blade length: 550mm to 600mm
-Tail blade length: 95 to 105 mm
-Main rotor diameter: 1270 mm (with 570 mm blades included)
-Tail rotor diameter: 260 mm (with 95 mm tail blades included)
-Cyclic Servos: mini cyclic servo (torque over 8 Kg-cm). Kit includes servo mounts for mini-servos. Full size servo mounts available separately.
-Tail Servo: standard size 40mm.
-Main Rotor ratio : 11.5 to 8.6 :1 ( 22T included: 9.4:1)
-Tail Rotor ratio : 5.3-4.9:1 ( 23T included: 4.9:1 )
-Typical motor : 4025 series, 6S 1000-1200 Kv, 12S 500-600 Kv. Minimum motor shaft length is 26mm (We recommend using a 6mm diameter motor shaft)
-Typical speed controller: 6S 120-140 A, 12S 100-130A
-Battery size: 6S 5000/5800 mAh, 12S 2600/3200 mAh.
